Peplink MAX HD4 IP67
Peplink MAX HD4 IP67
Dual 4G LTE Outdoor Mobile Router
Dual 4G LTE Outdoor Mobile Router
#MAX-HD4-M-LTEA-W-IP67
Our Price: Request a Quote
Our Price: Request a Quote
More pricing below, click here!
Please Note: All prices displayed are Ex-VAT. 20% VAT is added during the checkout process.
Overview:
Dedicated for Heavy-Duty Applications
The HD4 IP67 outdoor router has a waterproof IP67 metal enclosure that stands up to dust, vibration, and inclement weather. And, it is certified shock and vibration resistant, making it a great choice for construction, drilling, and other heavy-duty applications.
- Dust Protection
- Shock & Vibration Protection
- Water Proof (IP-67 Enclosure)
Quad Cellular and Redundant SIM slots for Multiple Carrier.
The HD4 IP67 includes four built-in outdoor 4G LTE/3G modems and four Redundant SIM slots. It allows you to use the same or different cellular providers for bandwidth bonding or eliminating blind spots. List of supported 4G LTE carriers at: peplink.com/lte-networks/
Speed & Reliability. Brought by SpeedFusion™
SpeedFusion bandwidth bonding technology bonds all connected bandwidth into a single superfast stream, using the same or different cellular providers.
Fleet Tracking and Management
With built-in GPS fleet tracking and InControl 2 cloud-based management, you can keep tabs on location and manage your mobile network from any Internet-connected device.
Specifications:
| MAX HD IP67 | |
|---|---|
| Ethernet WAN Ports | 1(GE) |
| Ethernet LAN Ports | 1(GE) |
| Embedded 4G LTE | 4 |
| SIM Card Size | Mini-SIM (2FF) |
| Recommended Users | 500 |
| Router Throughput ^ | 400Mbps |
| 802.1q VLANs Supported | 128 |
| Drop-in Mode | Yes |
| High Availability | Yes |
| WAN as LAN | Yes |
| Web Blocking | Yes |
| Web Filtering Blacklist | Lite |
| PepVPN | Yes |
| SpeedFusion - Hot Failover/WAN Smoothing/ Bandwidth Bonding | Yes |
| Number of PepVPN SpeedFusion Peers | 2/20 (&) |
| PepVPN/SpeedFusion Throughput (No Encryption) | (256-bit AES) | 150Mbps | 120Mbps |
| InControl Cloud Management/GPS Fleet Management | Yes |
| Manage Pepwave AP Series | Yes |
| Maximum Number of AP Support | 30 |
| Enclosure. Ingress Protection Rating | IP-67 |
| PoE Output | 1x 802.3at PoE Output (Requires 56V DC input for full 25.5W PoE+ Output) |
| Power Input | DC: 12V - 56V # |
| Power Consumption | 38W (max. w/o PoE) |
| Dimensions | 11.6 x 15.3 x 2.6 inches | 295 x 390 x 66 mm |
| Weight | 9.48 pounds | 4.3 kg |
| Operating Temperature | -40° - 149°F | -40° - 65°C |
| Humidity | 15% - 95% (non-condensing) |
| Certifications | FCC, CE, RoHS EN 61373:2010 (Shock and Vibration Resistance) |
| Package Content | MAX HD4 IP67 Waterproof Power Connector Kit 2x Waterproof Ethernet Connector Kit Mounting Kit |
| Power Requirement | 10V - 30V DC |
| Warranty | 1-Year Limited Warranty |
Documentation:
Download the MAX HD4 IP67 Datasheet (PDF).
